Linea Full Screen
A Tall Format Digital Kiosk for High Impact Public Spaces
The Linea Full Screen is a large format vertical digital kiosk designed for environments where visibility, presence, and physical impact matter. From retail flagships and shopping centres to corporate lobbies and public venues, it delivers a commanding visual experience in a slim, elegant kiosk form factor.
Built as a commercial grade kiosk enclosure and designed for continuous operation in public spaces, Linea Full Screen combines architectural presence with the flexibility of modern digital signage.
Designed for Real World Environments
Linea Full Screen is purpose built for high traffic, high visibility locations where standard screens simply disappear. Its tall vertical canvas and freestanding design make it ideal for:
- Shopping centres and retail flagships
- Corporate lobbies and headquarters
- Airports, stations, and transit hubs
- Hospitals and healthcare facilities
- Museums, galleries, and event spaces
A Physical Presence That Draws Attention
Unlike wall mounted displays or standard kiosks, Linea Full Screen creates a strong vertical landmark that is visible across open spaces and long sightlines.
Its height and proportions are designed to:
- Capture attention from a distance
- Align content naturally within human sightlines
- Stand out in architecturally open environments
- Create a premium, gallery like presentation surface
This makes it especially effective for entrances, atriums, and central circulation areas where impact matters most.
Built as a Commercial Kiosk Platform
Linea Full Screen is not a consumer display in a stand. It is a purpose built commercial kiosk designed for public deployment.
Key characteristics include:
- Rigid metal enclosure and stable base
- nternal component mounting and cable management
- Service access for maintenance
- Designed for continuous operation
- Clean, minimal industrial design that integrates into modern spaces
This makes it especially effective for entrances, atriums, and central circulation areas where impact matters most.
Deployment and Use Cases
Linea Full Screen is commonly deployed as:
- Brand storytelling and promotional totems
- Building and campus directories
- all and venue wayfinding kiosks
- Event and exhibition signage
- Corporate communications displays
- Public information and announcement boards
Its tall format makes it especially well suited for content that benefits from vertical composition and strong visual hierarchy.
Technical Specifications
| Category | 70 Inch Stretched LCD Display |
|---|---|
| Display Type | Commercial LCD panel |
| Diagonal Screen Size | 70 inch |
| Outline Size | 1735 × 692 mm |
| Display Area | 1635 × 633 mm |
| Native Resolution | 3840 × 1488 |
| Brightness | 450 nits adjustable |
| Viewing Angle | 89° / 89° / 89° / 89° (Up, Down, Left, Right) |
| Response Time | 5 ms |
| Panel Life | 50,000 hours or more |
| Touch | No |
| Audio Output | 5W × 2 speakers |
| Input Power | AC 90 to 240 V |
| Power Consumption | Less than 180 W |
| Enclosure | Industrial iron cabinet |
| Front Protection | High transparency tempered glass, 4 to 5 mm thickness |
| Surface Finish | Industrial powder coating with anti wear texture |
| CPU | Rockchip RK3568 quad core up to 2.0 GHz |
| GPU | Mali G52 supports OpenGL ES 1.1, 2.0, 3.2, OpenCL 2.0, Vulkan 1.1 |
| Memory | 2 GB DDR3 |
| Storage | 32 GB NAND Flash |
| External Storage | Supports SD card up to 32 GB |
| Power Supply | Industrial grade power module AC 100 to 240 V 50 or 60 Hz |
Part of the Linea Family by MediaTile
The Linea Full Screen kiosk is part of the Linea display family by MediaTile and is designed to integrate seamlessly into a complete digital signage ecosystem, from content management to network deployment.
