Linea Full Screen Kiosks
Linea Full Screen is a vertical, ultra tall digital signage kiosk designed for spaces where a standard 16:9 display does not provide enough visual presence.
Its tall portrait format creates a continuous, full height canvas that allows content to flow naturally from top to bottom, making messages easier to scan and more visually commanding in public environments.
This kiosk is well suited for locations such as retail centers, corporate lobbies, healthcare facilities, campuses and transportation hubs where visual hierarchy, clarity and impact are more important than fitting content into a traditional screen shape.
When Standard Screens Are Not Enough
Most digital signage is built around the 16:9 format, which works well for video but often limits how information can be arranged in vertical spaces. Linea Full Screen takes a different approach by offering a tall, uninterrupted display area that better matches architectural sight lines and how people move through a space.
The ultra tall format makes it possible to stack content vertically, combine branding with wayfinding, or create long format visual stories that simply do not fit on conventional displays.
Built to Be Seen in Public Spaces
Linea Full Screen is designed as a floor standing kiosk for indoor environments where durability and presence matter. The full screen design minimizes visual interruptions and keeps the focus on the content, while the vertical orientation naturally draws the eye upward and downward across the entire display surface.
This makes it especially effective in entrances, corridors and open areas where a strong visual anchor is needed.
A Display Format That Changes How You Design Content
The tall screen layout encourages a different approach to content design. Instead of forcing layouts into wide horizontal zones, designers can build experiences that feel more like posters, signage towers or vertical storytelling panels.
This format is ideal for directories, brand narratives, promotional stacks, announcements and multi section informational displays that benefit from a clear top to bottom reading flow.
Where It Fits Best
Retail and commercial environments
Ideal for storefronts, mall corridors and promotional zones where vertical layouts help messages stand out and guide attention naturally.
Corporate and office buildings
Well suited for lobby communication, brand storytelling, announcements and visitor information in shared spaces.
Healthcare and education
Useful for directories, schedules, wayfinding and general information where structure and clarity are important.
Transportation and public venues
A strong choice for guidance, directory style layouts and informational content in terminals, concourses and public halls.
Linea Full Screen Kiosks
| Category | 70 Inch Stretched LCD Display |
|---|---|
| Display Type | Commercial LCD panel |
| Diagonal Screen Size | 70 inch |
| Outline Size | 1735 × 692 mm |
| Display Area | 1635 × 633 mm |
| Native Resolution | 3840 × 1488 |
| Brightness | 450 nits adjustable |
| Viewing Angle | 89° / 89° / 89° / 89° (Up, Down, Left, Right) |
| Response Time | 5 ms |
| Panel Life | 50,000 hours or more |
| Touch | No |
| Audio Output | 5W × 2 speakers |
| Input Power | AC 90 to 240 V |
| Power Consumption | Less than 180 W |
| Enclosure | Industrial iron cabinet |
| Front Protection | High transparency tempered glass, 4 to 5 mm thickness |
| Surface Finish | Industrial powder coating with anti wear texture |
| CPU | Rockchip RK3568 quad core up to 2.0 GHz |
| GPU | Mali G52 supports OpenGL ES 1.1, 2.0, 3.2, OpenCL 2.0, Vulkan 1.1 |
| Memory | 2 GB DDR3 |
| Storage | 32 GB NAND Flash |
| External Storage | Supports SD card up to 32 GB |
| Power Supply | Industrial grade power module AC 100 to 240 V 50 or 60 Hz |
