Linea Interactive Kiosks
Self service and digital information kiosks built for real world use
The Linea series from humanKIOSK is a versatile family of floor standing digital kiosks designed for self service, wayfinding and information display in public spaces. Available in 32, 43, 49, 55, 65, 75 and 85 inch sizes, Linea uses commercial LED backlit displays with support for up to 3840×2160 resolution and can be ordered with or without touch.
Whether you are deploying a simple digital directory or a fully interactive self service station, Linea provides a clean and professional platform that runs the software you choose.
Key Capabilities
Clear and detailed displays
Linea kiosks use commercial LED panels capable of displaying up to 16.7 million colours with wide 178 degree viewing angles and fast 8ms response time. All models support up to 3840×2160 resolution, making them suitable for detailed layouts, maps, schedules and interactive interfaces. Brightness is rated at 300 nits for the 32 inch model and 350 nits for all larger sizes.
Sizes to fit any space
Choose from 32, 43, 49, 55, 65, 75 or 85 inch displays to match your environment, viewing distance and content layout. This flexibility makes it easy to deploy the same kiosk platform across different locations while adjusting screen size to suit each space.
Optional multi touch interaction
Linea is available in both standard and touch enabled versions. Touch models use PCAP touch technology on 32" to 65" sizes and IR 10 point touch on 75" and 85" sizes, and maintain the same display specifications as the non touch versions, allowing you to mix interactive and non interactive kiosks within the same project.
Built for long service life
All Linea displays are rated for 50,000 hours of operation. They are designed to operate in environments from 0°C to 50°C and can be stored in temperatures from -20°C to 60°C.
Easy to deploy
Linea supports universal AC power from 100 to 240 volts at 50 or 60 hertz, making it suitable for installations in North America and internationally.
Common Applications
Wayfinding and directories
Use Linea kiosks to provide interactive maps, staff directories, tenant lists and navigation tools in hospitals, campuses, offices and large facilities.
Visitor check in and self service
Touch models are ideal for visitor registration, appointment check in, queue management and basic self service workflows.
Corporate environments
Install Linea in reception areas, elevator lobbies or shared work zones to share corporate news, performance dashboards, internal campaigns and visitor guidance. Touch enabled units can support wayfinding, room searches and simple self check in workflows.
Information and communications
Display schedules, announcements, alerts and educational content in high traffic areas where clear communication is essential.
Public buildings and institutions
Deploy Linea in government buildings, libraries, museums and transportation facilities to provide guidance, information and interactive services.
Linea Digital Kiosks
| Category | LK 32" | LK 43" | LK 49" | LK 55" | LK 65" | LK 75" | LK 85" |
|---|---|---|---|---|---|---|---|
| Model No | LK-32 | LK-43 | LK-49 | LK-55 | LK-65 | LK-75 | LK-85 |
| Panel Type | 32" LED backlight | 43" LED backlight | 49" LED backlight | 55" LED backlight | 65" LED backlight | 75" LED backlight | 85" LED backlight |
| Display Area (mm) | 700mm (H) × 392mm (W) | 928mm (H) × 522mm (W) | 1073.8mm (H) × 604mm (W) | 1209mm (H) × 680mm (W) | 1428.5mm (H) × 803.5mm (W) | 1649.66mm (H) × 927.936mm (W) | 1872mm (H) × 1053mm (W) |
| Aspect Ratio | 16:09 | 16:09 | 16:09 | 16:09 | 16:09 | 16:09 | 16:09 |
| Maximum Resolution | 3840×2160 | 3840×2160 | 3840×2160 | 3840×2160 | 3840×2160 | 3840×2160 | 3840×2160 |
| Display Color | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M |
| Pixel Pitch (mm) H×W | 0.36375mm (H) × 0.36375mm (W) | 0.485mm (H) × 0.485mm (W) | 0.485mm (H) × 0.485mm (W) | 0.630mm (H) × 0.630mm (W) | 0.744mm (H) × 0.744mm (W) | 0.4296mm (H) × 0.4296mm (W) | Not listed |
| Brightness (nits) | 300nits | 350nits | 350nits | 350nits | 350nits | 350nits | 350nits |
| Contrast Ratio | 1000:1 | 1000:1 | 1100:1 | 1400:1 | 1400:1 | 1200:1 | Not listed |
| Visual Angle | 178°/178° | 178°/178° | 178°/178° | 178°/178° | 178°/178° | 178°/178° | 178°/178° |
| Response Time | 8ms | 8ms | 8ms | 8ms | 8ms | 8ms | 8ms |
| Life (hrs) | 50,000hrs | 50,000hrs | 50,000hrs | 50,000hrs | 50,000hrs | 50,000hrs | 50,000hrs |
| Touch | N/A | N/A | N/A | N/A | N/A | N/A | N/A |
| Operating Temp | 0°C~50°C | 0°C~50°C | 0°C~50°C | 0°C~50°C | 0°C~50°C | 0°C~50°C | 0°C~50°C |
| Storage Temp | -20°C~60°C | -20°C~60°C | -20°C~60°C | -20°C~60°C | -20°C~60°C | -20°C~60°C | -20°C~60°C |
| Power | AC100~240V 50/60 HZ | AC100~240V 50/60 HZ | AC100~240V 50/60 HZ | AC100~240V 50/60 HZ | AC100~240V 50/60 HZ | AC100~240V 50/60 HZ | AC100~240V 50/60 HZ |
| Category | LK 32" Touch | LK 43" Touch | LK 49" Touch | LK 55" Touch | LK 65" Touch | LK 75" Touch | LK 85" Touch |
|---|---|---|---|---|---|---|---|
| Model No | LK-32-T | LK-43-T | LK-49-T | LK-55-T | LK-65-T | LK-75-T | LK-85-T |
| Touch | PCAP Touch | PCAP Touch | PCAP Touch | PCAP Touch | PCAP Touch | IR 10 Point Touch | IR 10 Point Touch |
| All Other Specs | Same as the corresponding non touch model above | ||||||
